Defender TLC 300 APC
Vehicle Specifications
| Make: | Toyota |
| Model: | Land Cruiser 300 |
| Body Style | Special Purpose |
| Armor Level | CEN B6 |
| Transmission | 10 Speed Automatic |
| Engine | 3.5L Twin Turbo (3346 cc) |
| Horsepower | 409 hp |
| Drivetrain | 4WD |
| Dimension (L×W×H) | 5151 × 2059 × 2166 mm |
| Wheelbase | 2880 mm |
| Seating Capacity | 2 + 6 |
| Fuel Capacity | 110 L |
| Payload | 950 Kg |
| Max Speed | 120 KM/H |
Defender TLC 300 APC
Vehicle Specifications
| Make: | Toyota |
| Model: | Land Cruiser 300 |
| Body Style | Special Purpose |
| Armor Level | CEN B6 |
| Transmission | 10 Speed Automatic |
| Engine | 3.5L Twin Turbo (3346 cc) |
| Horsepower | 409 hp |
| Drivetrain | 4WD |
| Dimension (L×W×H) | 5151 × 2059 × 2166 mm |
| Wheelbase | 2880 mm |
| Seating Capacity | 2 + 6 |
| Fuel Capacity | 110 L |
| Payload | 950 Kg |
| Max Speed | 120 KM/H |
The Secure Armoured B6 protection level APC based on Toyota Land Cruiser300 is a highly protected and reliable armored vehicles designed to provide maximum protection for its occupants in high-risk environments.The salient features of the vehicle are given below.
Standard Armoring Features
1. Vehicle Model: Toyota Land Cruiser 300, 3.5L twin-turbo V6 engine producing 409 Horsepower, 650 Nm Torque.
2. Protection Level: CEN B6 (Ballistic Protection Level), 2x DM51 blast protection.
3. Armor Material: High-strength ballistic protection steel, and transparent armor.
4. Transparent Armor: The windows are fitted with transparent armor made of multi-layered glass and polycarbonate to protect against ballistic threats.
5. Suspension System: Upgraded heavy-duty suspension system to support the additional weight of the armor without compromising the vehicle’s performance.
6. Engine: Powerful engine to ensure the vehicle can carry the added weight of the armor and still maintain high performance levels.
7. Braking System: Upgraded braking system for improved stopping power and control under heavy loads.
8. Run-flat Inserts & Off-road Tires: The vehicle is equipped with off-road tires having run-flat inserts that allow it to continue driving even if the tires are hit or punctured. The vehicle can equally drive in rough off-road terrain.
9. Additional Features:
Heavy duty reinforced door hinges and latches for added security
– Emergency escape hatches for quick evacuation in case of emergency
10. Interior Features:
– Comfortable seating for passengers with ample legroom and headspace
– Climate control system for a comfortable ride in all-weather condition.
- Armor Type: Ballistic steel and opaque armor
- Protection Level: Stanag 2 Level
- The vehicle resists multiple 7.62x51 mm FMJ, PB, and AP rounds, ensuring superior armor-piercing protection.
- The vehicle provides full protection from DM-51 grenades & resists anti-tank mines with innovative V-flooring that deflects blast energy.
- IED side blasts: The doors overlaps are specially designed to provide protection against side IED blasts.
- Additional Protection: Optional additional protection of spall liner
- Payload: Approximately 2000kg TBC
- Cargo Area: Optional rear foldable seats offering large cargo space of L3000xW1000xH1250 TBC
- Special Equipment: 12000 lb winch capacity, towing & tie down and vehicle lifting lugs
- Out-side Bins Storage Capacity: The outside of vehicle has bins having huge storage capacity
- Crew Configuration: 1 Driver, 1 Commander, 1 Gunner, 1 Radio Operator, 6 Infantry
- Main Armament: 7.62x51mm MG or 12.7mm MG can be mounted on universal gun mount in turret
- Personal Weapons: Solider carrying 7.62mm assault rifles can be secured on rifle holders and also can be used to shoot through 9 gunports covering vehicle sides and rear
- Ammunition Capacity: Ammo Box of storage 1000 rounds for Main armament, and 2000 rounds for Personal Weapons can be stored inside vehicle
- Turret System: Open turret with clear field of view and 2 x side glasses for situational awareness
- Fire Control System: 2 x Manual Fire Extinguishers, Optional Automatic Fire Suppression System
- Communication Systems: provision to mount VHF antennas can be provided along with radio rack, intercom for enhanced internal communication
- Navigation System: Optional GPS equipment
- Surveillance Systems: Thermal, night vision and 360-degree cameras can be provided as optional equipment
Customization Options
- Vehicle can be customized as per user requirement
Standard Armoring Features
- Armor Type: Ballistic steel and opaque armor
- Protection Level: Stanag 2 Level
- The vehicle resists multiple 7.62x51 mm FMJ, PB, and AP rounds, ensuring superior armor-piercing protection.
- The vehicle provides full protection from DM-51 grenades & resists anti-tank mines with innovative V-flooring that deflects blast energy.
- IED side blasts: The doors overlaps are specially designed to provide protection against side IED blasts.
- Additional Protection: Optional additional protection of spall liner
- Payload: Approximately 2000kg TBC
- Cargo Area: Optional rear foldable seats offering large cargo space of L3000xW1000xH1250 TBC
- Special Equipment: 12000 lb winch capacity, towing & tie down and vehicle lifting lugs
- Out-side Bins Storage Capacity: The outside of vehicle has bins having huge storage capacity
- Crew Configuration: 1 Driver, 1 Commander, 1 Gunner, 1 Radio Operator, 6 Infantry
- Main Armament: 7.62x51mm MG or 12.7mm MG can be mounted on universal gun mount in turret
- Personal Weapons: Solider carrying 7.62mm assault rifles can be secured on rifle holders and also can be used to shoot through 9 gunports covering vehicle sides and rear
- Ammunition Capacity: Ammo Box of storage 1000 rounds for Main armament, and 2000 rounds for Personal Weapons can be stored inside vehicle
- Turret System: Open turret with clear field of view and 2 x side glasses for situational awareness
- Fire Control System: 2 x Manual Fire Extinguishers, Optional Automatic Fire Suppression System
- Communication Systems: provision to mount VHF antennas can be provided along with radio rack, intercom for enhanced internal communication
- Navigation System: Optional GPS equipment
- Surveillance Systems: Thermal, night vision and 360-degree cameras can be provided as optional equipment
Customization Options
- Camouflage: digital, desert, forest or user required color camouflage can be offered
- Upgrades: Higher protection armor packages can be offered, additional weaponry is optional
- Special Features: Vehicle can be customized as per user requirement
